Dam water level monitor swj-1, reservoir water level monitor swj-1-1
Measurement signal: liquid level transmitter / differential pressure transmitter
Measurement accuracy: Nonlinearity is <0.25%
Digital display content: water level value / water head value, 4-road alarm output setting value
Switch quantity output signal: 4 channels, each point can be fixed by the user within the specified range
Analog quantity output: 4~20ma
Output contact capacity: 5a / 250vac, 5a / 30vdc
Working environment: temperature 0~50℃ and humidity <85%
Overall dimension: plate-mounted 16080250mm
Power supply: 110v / 220vdc or ac110 / 220v / 50Hz
