XMZ-3 water level difference monitor
Goods number; 6789
Brand; Hengyuan
Model number; XMZ-3
Measurement range; 0-9999
Resolution; 0.25
Power supply voltage; 220
Overall dimensions; 160 * 80 (mm)
Explosion-proof grade; IP68
Measurement accuracy; 0.25
specifications;XMZ
Input signal: water level transmitter output 4-20m, with four-way input.
Precision: 0.5% F.S or 0.2%F.S± in 1 word
Display mode: six digital pipe, the range of 0.00~9999.99 meters, can display the altitude, optional LCD display.
Alarm output: two limit alarm, the alarm mode can be set, the relay output contact capacity of AC220V / 3A or AC220V / 1A.
Transmission output: 4~20mA, 0~10mA, 1~5V, 0~5V accuracy: ± 0.3%FS, with up to 5-circuit output.
Communication output: interface mode —— isolation serial two-way communication interface RS485 / RS422 / RS232 / Modem
Baud rate —— 300~9600bps internal free set
Transmitter power supply: DC24V±1.2V/0.2A (equipped according to user needs)
Instrument power supply: AC85V~265V, 50Hz or DC24V
Display mode and scope:
Front water level-top six red LED display, 0-9999.99 m
Water level behind the gate- - - - - - - -middle six red LED display, 0-9999.99 m
Water level difference- - - - -the lower row of six red LED shows, 0-9999.99 meters
