Flow switch FCS-G1/2A4P-LIX-H1141/D037
Product use: multiple media flow monitoring
Goods number: 12252
Processing customization: Yes
Brand: Lantian Hengyuan
Model: FCS-G1 / 2A4P-LIX-H1141
Technical parameters of the FCS flow switch
Medium and flow rate: water: 0 ~ 5 m/s; oil 0 ~ 10 m/s; gas 0 ~ 50 m/s;
Repeatability: ± 1% set point range;
Response time: typical 2s, maximum 15s
Pressure resistance rating: 10MPa
Medium temperature range: -25℃ -80℃
Operating voltage: DC 24VDC; AC AC220V;
Current consumption: 65mA
Connection: G1 / 2'M201.5 (special ordering)
Enclosure protection: a stainless steel housing for IP67 protection
